How to get a useful result
A screen test is only as good as the conditions you run it in. Use 100% browser zoom and the display's native resolution, turn off night light, blue-light filters and dynamic contrast, let the panel warm up for a few minutes, and view from your normal seating position in a dim room.
Most panels fail something. A little corner glow on IPS, faint banding on an 8-bit panel and slight tint shift off-axis are normal manufacturing variance. What warrants a return is a fault you can see during ordinary use from a normal distance, check your manufacturer's dead-pixel policy before filing a claim.
Test patterns, pixel fault classes and panel types
Use these tables after the inspection station above. The first says which pattern reveals which fault. The second shows the ISO pixel fault classes that many monitor makers base their dead-pixel policies on. The third explains what is normal for each panel type, so you do not return a monitor for IPS glow or VA smearing it was always going to have.
| Pattern | Finds | What to look for |
|---|---|---|
| Black | Backlight bleed, IPS glow, lit (hot) pixels | Dim the room. Light fixed at the edges is bleed; glow that moves when you move your head is IPS glow. |
| White | Dead pixels, dust under the glass, tint patches | Scan the screen in quarters. Dark specks are dead pixels or dust. |
| Red | Stuck or dead red sub-pixels | A dark dot means that red sub-pixel is off; a green or blue dot is stuck. |
| Green | Stuck or dead green sub-pixels | Same check as red, for the green channel. |
| Blue | Stuck or dead blue sub-pixels | Same check as red, for the blue channel. |
| 50% gray | Clouding, dirty screen effect, OLED retention | Look for darker streaks, blotches or a faint old image. |
| 1px checkerboard | Scaling blur, wrong resolution, shimmer | At 100% zoom the pattern should look like even fine gray texture, with no waves or blur. |
| Gradient | Banding and low bit depth | A smooth ramp is good. Clear vertical stripes mean banding. |
| Class | Always-lit pixels | Always-dark pixels | Faulty sub-pixels | Typical use |
|---|---|---|---|---|
| Class 0 | 0 | 0 | 0 | Medical and mission-critical panels |
| Class I | 1 | 1 | 2 | Premium professional monitors |
| Class II | 2 | 2 | 5 | Most consumer monitors and laptops |
| Class III | 5 | 15 | 50 | Budget panels |
| Class IV | 50 | 150 | 500 | Industrial and low-cost displays |
| Resolution | Megapixels | Always-lit | Always-dark | Faulty sub-pixels |
|---|---|---|---|---|
| 1080p Full HD (1920 × 1080) | 2.07 | 4 | 4 | 10 |
| 1440p QHD (2560 × 1440) | 3.69 | 7 | 7 | 18 |
| 4K UHD (3840 × 2160) | 8.29 | 16 | 16 | 41 |
| Panel | Normal behaviour | Fault worth checking | Best test here |
|---|---|---|---|
| IPS | Corner glow that changes with viewing angle | Bright patches fixed at the edges (bleed) | Black screen, gray uniformity |
| VA | Dark smearing in fast motion, gamma shift off-axis | Clouding or uneven blacks | Pixel response, viewing angle |
| TN | Strong colour shift when viewed from above or below | Banding in gradients | Gradient, viewing angle |
| OLED | Perfect black, slight near-black tint on some panels | Faint retained image from static UI (burn-in) | OLED burn-in test, 50% gray |
| Mini-LED | Halo around bright objects on black (blooming) | Dead dimming zones | Black screen, white screen |
Check your retailer's return window first (often 14 to 30 days). Shops usually accept returns for faults that a manufacturer's pixel policy would still call acceptable.
What these tools can and cannot tell you
They show controlled patterns so you can see a symptom. They cannot measure brightness, colour accuracy or response time in numbers, cannot identify which component failed, and cannot repair dead pixels or physical damage. The fake update screens are visual replicas and are not affiliated with Microsoft, Apple or Canonical.
Frequently asked questions
What is the quickest way to test a new monitor?
Show white and black fullscreen to look for dead and stuck pixels, then gray uniformity for backlight bleed and the gradient test for banding. Most problems worth returning a monitor for show up in those four checks.
Do these display tools upload anything?
No. Patterns, colours, timers and settings are generated in your browser. Nothing is sent to a server and no account is needed.
Can a browser test measure color accuracy or response time?
No. A browser can display patterns for a visual comparison. Exact Delta E, gamma, brightness or millisecond response times need a hardware colorimeter or measurement rig.
How many dead pixels are allowed on a new monitor?
Most consumer monitors follow ISO pixel fault Class II: per million pixels, up to 2 always-lit, 2 always-dark and 5 faulty sub-pixels. On a 1440p screen that works out to about 7 always-dark pixels and 18 faulty sub-pixels. Many brands publish stricter policies, so check yours.
Will these tools work on a phone or TV?
Yes. They run in any modern browser. On a TV, open the page in the TV browser or cast the tab; on iPhone, adding the page to the Home Screen gives a cleaner fullscreen view.
